Harvard CourtTenant manual
← All rooms

Room guide

Kitchen / breakfast room

The kitchen contains the Neff integrated dishwasher documented in this edition.

Floor plan: 13'6 × 13'6 max
Floor plan of 24 Harvard Court Reception Study Entrance Kitchen Shower room Kid's bedroom Main bedroom Bath room
Choose a room on the plan. A complete room menu is also available at the top of every page.
01

Confirmed so far

At a glance

Kitchen sink cold valveA
Kitchen sink hot valveD
Dishwasher modelNeff S513K60X1G
Usual dishwasher programme1h programme
Internet connectionA Hyperoptic cable already arrives in the kitchen. If you choose Hyperoptic, connecting the service should be straightforward and should only require a new router.
BoilerProvides heating only. It is old, but works well.
Worktop careThe worktop needs some coats of worktop oil every six months. Follow the directions on the tin.
Small hand toolsKept in the kitchen. The tin contains keys and locks for securing the windows, plus radiator bleeding keys.
02

Integrated appliance

Neff dishwasher

ModelS513K60X1G

E-NrS513K60X1G/18

FD0003

Z-Nr00039

  1. Load with space for the spray arms.Keep the detergent cover and tablet area clear.
  2. Add dishwasher detergent.Add special salt or rinse aid when its indicator shows.
  3. Choose a programme and press Start.The household usually used the 1h programme. The supplied manufacturer documents also describe Eco 50°C, Auto 45–65°C and Chef 70°C for stubborn residue.
  4. Close the door fully.The red InfoLight on the floor means the machine is running.
Faults E:15, E:24 or E:25

E:15: turn off the water and appliance, then report it. E:24 points to drainage; E:25 to a blocked pump or unlocked cover. Switch off and disconnect power before any filter-area check. Do not tilt or dismantle the integrated machine.

Neff dishwasher rating plate and controls
The rating plate confirms the appliance identifiers.

Manufacturer documents

Quick referencePDFFull instruction manualPDFProduct specificationPDFRack loading guidePDFInstallation guidePDFHose clearance notePDFEnergy dataPDF

Two supplied repair videos were reviewed but are not reproduced as tenant instructions: both involve invasive pump or leak work better left to an authorised repairer.

03

Owner input needed

Questions for this room

01

Where are valves A and D physically accessed?

02

What are the makes, models and basic instructions for the oven, hob and fridge-freezer?
